Technical parameter |
||
|
Drilling depth(M) |
400 |
|
|
Drilling diameter(mm) |
500 |
|
|
Speed of turntable(r/min) |
21.2;36;63.2;100.6;155;20.2(reverse) |
|
|
Torque of turntable(KN.m) |
18;10.6;6;3.8;2.5;18.9(reverse) |
|
|
Single rope lifting capacity of windlass(KN) |
45 |
|
|
The lifting capacity of hook(KN) |
270 |
|
|
Bearing capacity of mast (KN) |
270 |
|
|
The height of mast (mm) |
11500 |
|
|
Bearing capacity (t) |
30 |
|
|
Pipe |
Kelly bar(mm) |
108×108×7500 |
|
Assistant pipe (mm) |
89×10×5500 |
|
|
Hydraulic pump |
Model |
CB-HP80/40 |
|
Pump delivery (ml/r) |
80/40 |
|
|
Rated speed (r/min) |
2000 |
|
|
Rated pressure(MPa) |
20 |
|
|
BW850/2A plunger pump
|
Diameter of cylinder (mm) |
150 |
|
Stroke of piston (mm) |
180 |
|
|
Theory of flow (L / min) |
600 850 |
|
|
Rated pressure (Mpa) |
3 2 |
|
|
Pounding times (min-1) |
58 82 |
|
|
Diameter of suction tube (mm) |
127 |
|
|
Diameter of drain pipe (mm) |
64 |
|
|
Input speed (r / min) |
470 |
|
|
Input power (kw) |
40 |
|
|
Overall dimensions (mm) |
2000*1030*1400 |
|
|
Weight (t) |
1.5 |
|
